ایسی امپلی فایر(تقویت کننده) RF - RF Amplifier .1-4GHz NF .8dB Gain 15.3dB
Applications
Repeaters
Mobile Infrastructure
LTE / WCDMA
General Purpose Wireless
Product Features
50 – 4000 MHz
15.3 dB Gain at 1.9 GHz
0.8 dB Noise Figure at 1.9 GHz
<1.5:1 I/O VSWR ( >14 dB I/O Return Loss)
+34 dBm Output IP3
+22.3 dBm P1dB
50 Ohm Cascadable Gain Block
Unconditionally Stable
High Input Power Capability
Single Supply, 50 mA Current
| Product Attribute | Attribute Value |
|---|---|
| Qorvo | |
| RF Amplifier | |
| RoHS: | Details |
| SMD/SMT | |
| QFN-16 | |
| Low Noise Amplifiers | |
| Si | |
| 50 MHz to 4 GHz | |
| 22.3 dBm | |
| 15.3 dB | |
| 5 V | |
| 0.8 dB | |
| 34 dBm | |
| 50 mA | |
| - 40 C | |
| + 105 C | |
| TQP3M9005 | |
| Reel | |
| Cut Tape | |
| MouseReel | |
| Brand: | Qorvo |
| Product Type: | RF Amplifier |
| 2500 | |
| Subcategory: | Wireless & RF Integrated Circuits |
| Supply Voltage - Max: | 5.5 V |
| Supply Voltage - Min: | 4.5 V |
| Test Frequency: | 1.9 GHz |
| Part # Aliases: | 1071864 1071864 |
| Unit Weight: | 0.002014 oz |
