CSC7203 اورجینال - کیفیت بالا

نقد و بررسی اجمالی

ایسی ساخت انواع منابغ تغذیه و باتری شارژر HIGH PERFORMANCE OFF-LINE PWM SWITCHING POWER CONVERTER

استفاده در انواع صنایع از جمله نوسان ساز(PWM)انواع بردهای درایو دستگاه های جوش و برش و اینورتری
درایورهای دور موتور و .....

ساخت انواع اداپتور

منابع تغذیه

1. DESCRIPTION
   The CSC7203 is a high performance
   current mode Pulse Width Modulated (PWM)
   switching power converter, which meets the
   Green Environmental standards. It is widely
   used in economical switching power supply,
   such as Set-top Box, DVD, printer and LCD
   display, etc..
   FEATURES
    Built-in 700V High Power BJT
    Full Input Voltage Range: 85VAC ~
   265VAC
    Current Mode PWM Control
    Pulse-by-Pulse Current Limit Detected
    Built-in Ramp Drive Circuit
    Built-in Current Limit Resistor with
   Temperature Compensation
    Built-in Over Temperature, Over Current,
   Over Voltage and Over Load Protection
    Built-in Self-Powered Without Auxiliary
   Winding
    Internal Integrated Start-up Resistance,
2. Few Peripheral Devices
3. No-load Power Consumption < 0.3W
   and When VIN = 220VAC, Power
   Consumption < 0.2W
4. APPLICATIONS
5.  Intelligent mobile phone and small size
   table computer power supplies
    DVD and Set-top boxes power supplies
    Power adapters
