ای سی تقویت کننده،امپلی فایر،اپ امپ ابزار دقیق ،گین 1 تا 1000 ،در گین 1 دارای پهنای باند 800 کیلو هرتز می باشد. Single-Supply, Rail-to-Rail, Low Cost Instrumentation Amplifier
FEATURES
Easy to use
Higher performance than discrete design
Single-supply and dual-supply operation
Rail-to-rail output swing
Input voltage range extends 150 mV below ground (single supply
Low power, 550 μA maximum supply current
Gain set with one external resistor
Gain range: 1 (no resistor) to 1000
High accuracy dc performance
0.10% (gain accuracy (G = 1
0.35% (gain accuracy (G > 1
10 (ppm maximum gain drift (G = 1
200 (μV maximum input offset voltage (AD623A
2 (μV/°C maximum input offset drift (AD623A
100 (μV maximum input offset voltage (AD623B
1 (μV/°C maximum input offset drift (AD623B
25 nA maximum input bias current
(Noise: 35 nV/√Hz RTI noise @ 1 kHz (G = 1
Excellent ac specifications
90 (dB minimum CMRR (G = 10); 70 dB minimum CMRR (G = 1
at 60 Hz, 1 kΩ source imbalance
800 (kHz bandwidth (G = 1
20 (μs settling time to 0.01% (G = 10
APPLICATIONS
Low power medical instrumentation
Transducer interfaces
Thermocouple amplifiers
Industrial process controls
Difference amplifiers
Low power data acquisition
