Schottky Barrier Rectifier, 1A, 20V دیود شاتکی 20 ولت 1 آمپر - سایز 58 میلی متر
Schottky Barrier Rectifier, 1A, 20V
دیود شاتکی 20 ولت 1 آمپر
The Schottky Rectifier employs the Schottky Barrier principle in a large area metal-to-silicon power diode. The Schottky Rectifier¿s state-of-the-art geometry features chrome barrier metal, epitaxial construction with oxide passivation and metal overlap contact. It is ideally suited for use as rectifiers in low-voltage, high-frequency inverters, free wheeling diodes and polarity protection diodes.
Features | |
---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ویژگی |
مقادیر |
خانواده |
دیود |
سری دیود |
شاتکی |
تعداد پین | 2 |
پکیج |
DO-41 |
ولتاژکاری |
20V |
جریان کاری |
1A |
توان |
- |
VZ |
- |
VRRM | 20V |
VRMS |
- |
VDC |
- |
VF |
- |
(IF(AV)-I(AV |
1A |
IFRM |
- |
IFSM |
25A |
(IR(25°C |
1mA |
(IR(HIGH TEMP |
10mA |
CJ |
- |
Trr |
- |
ابعاد |
3.05x3.05x6.60mm |
دمای کاری |
125+~65- |
برند |
OTHER |
کشور سازنده |
تایوان |
کیفیت |
ارجینال |
نوع مونتاژ |
DIP |
ویژگی خاص |
- |
