رله تایمر امرن 8 پین اریجینال OMRON H3CR-A8-AC100-240/DC100-125 - Analog Timer, Multifunction, H3CR-A Series, On-Delay, 14 Ranges, 0.05 s, 300 h, 1 Changeover Relay
رله تایمر امرن 8 پین اریجینال
OMRON H3CR-A8-AC100-240/DC100-125 - Analog Timer, Multifunction, H3CR-A Series, On-Delay, 14 Ranges, 0.05 s, 300 h, 1 Changeover Relay
Functions - 111,453
LED indication of power and contact status
44.8 x 44.8mm panel cut out
Conforms to EMC standards
Panel mount adaptor and DIN rail socket are sold separately (see accessories).
UL, CSA
| Supply Voltage | 100 → 125 V dc, 100 → 240 V ac | |
| Time Range | 0.05 s → 300 h | |
| Mode of Operation | Flicker ON Start, Interval, ON Delay, One Shot | |
| Mounting Type | DIN Rail, Flush Mount, Surface Mount | |
| Number of Timer Functions | Multi Function | |
| Number of Contacts | 2 | |
| Series | H3CR | |
| Time Increment | Hours, Seconds | |
| Power Supply | External | |
| Current Maximum | 5 A | |
| Terminal Type | 8-Pin Connector | |
| Maximum Voltage | 125 V dc, 250 V ac | |
| Width | 48mm | |
| Length | 48mm | |
| Switch Configuration | DPDT | |
| Maximum Operating Temperature | +55°C | |
| Depth | 81.6mm | |
| Minimum Operating Temperature | -10°C | |
| CAD Drawing | 3D CAD Model |
