Fluke 750P07 Gauge Pressure Module, 0-35 Bar, 4X Burst Rating ماژول فشار جهت اتصال به دستگاه های کالیبراتور Fluke750P07 فلوک -فلویک
Fluke 750P Series Pressure Modules are easy to use. To measure pressure, connect the pressure module to a pressure source or hand pump and then connect the pressure module cable to the calibrator. Apply pressure from the pressure source and it is displayed digitally on the calibrator. At the touch of a button, the pressure may be displayed in up to 11 different engineering units. When used with the 750 Series Documenting Process Calibrators, pressure readings can be date/time stamped and stored electronically for later retrieval. This saves time, eliminates errors, and supports F85compliance with quality standards and regulations.
Features
Parameter Range | 0 to 500 psi (0 to 35 bar) |
Burst Rating | 4X |
Hi Side Media | 316 SS |
Lo Side Media | NA |
Reference Uncertainty | ±0.0175 % |
Total Uncertainty 1 year (15-35℃) | ± 0.035 % |
