ای سی تغذیه 20 وات،آفلاین سوئیچر Monolithic High Voltage Gated Oscillator Power Switching Regulator AC/DC Converters 700V 100mA Switching No Auxillary Winding
General Description
AC/DC Converters 700V 100mA Switching No Auxillary Winding
The NCP1050 through NCP1055 are monolithic high voltage
regulators that enable end product equipment to be compliant with low
standby power requirements. This device series combines the required
converter functions allowing a simple and economical power system
solution for office automation, consumer, and industrial products.
These devices are designed to operate directly from a rectified AC line
source. In flyback converter applications they are capable of providing
an output power that ranges from 6.0 W to 40 W with a fixed AC input
of 100 V, 115 V, or 230 V, and 3.0 W to 20 W with a variable AC input
that ranges from 85 V to 265 V
استفاده در انواع تجهیزات و دستگاه جوش های اینورتری
مشخصات:
مشخصات - پارامترها |
مقادیر |
خانواده |
مبدل ها |
سری |
Current Mode PWM Controller
|
تعداد پین |
4 |
پکیج |
SOT-223 |
ولتاژکاری |
10V |
جریان کاری |
100mA |
[RDSON[Ω |
22 |
[Ipeak [mA |
100 |
[Freq [kHz |
65-100-130 |
Output Power |
6-19W |
fOSC |
- |
Dmax |
74-80% |
ابعاد |
7.30X6.70X1.75mm |
دمای کاری |
150+~65- |
برند |
ON SEMI |
کشور سازنده |
- |
کیفیت |
ارجینال |
نوع مونتاژ | SMD |
ویژگی خاص | - |
