کارت خروجی امرن اصلی 64 خروجی Omron PLC Expansion Module Output 64 Output 12 → 24 V dc
کارت خروجی امرن اصلی 64 خروجی
Omron PLC Expansion Module Output 64 Output 12 → 24 V dc
The PNP transistor output module (Stock No. 512-5902) features short circuit protection and an output wire break sensing facility
Commons: 1 (8 for stock no. 510-1489)
Outputs: 16 (8 for stock no. 510-1489)
Current Consumption: 90mA @ 5Vdc (48mA @ 24Vdc) for stock no. 510-1489; 110mA @ 5Vdc (96mA @ 24Vdc) for 512-5895; 100mA @ 5Vdc only, for stock nos. 510-1495 and 512-5902
CJ1 Digital I/O, Analogue I/O, and Communication modules clip together to the right of the CPU in any combination up to a maximum of 10 modules. A further 10 modules can be connected to a CJ1M-CPU13 or CJ1M-CPU23 based system as part of an expansion assembly.
Dimensions: Height 90mm, Width 31mm, Depth 89mm
All modules have removable screw terminal blocks for I/O connections, except screwless (SL)
| For Use With | SYSMAC CJ Series | |
| Module Type | Output | |
| Output Type | Transistor | |
| Number of Outputs | 64 | |
| Voltage Category | 12 → 24 V dc | |
| Length | 95.4mm | |
| Width | 20mm | |
| Depth | 83.6mm | |
| Dimensions | 95.4 x 20 x 83.6 mm |
